Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 193
Empty calibration/
LOW_LEVEL_EASY
Options
Index: 100
Data type: FLOAT
Access: OOS
Enter the height value for the lower calibration point (container empty). Select
the unit via the Height unit/HEIGHT_UNIT_EASY parameter ( ä 190).
• In the case of wet calibration, the level (container empty) must actually be
available. The associated pressure is then automatically recorded by the
device.
• In the case of dry calibration, the level (container empty) does not have to be
available. The associated pressure has to be entered in the Empty pressure/
LOW_LEVEL_PRESSURE_EASY parameter for the "In pressure" level
selection. The associated height must be entered in the Empty height/
LEVEL_OFFSET_EASY parameter for the "In height" level selection.
Full pressure/
HIGH_LEVEL_PRESSURE_EA
SY
Entry
Index: 101
Data type: FLOAT
Access: OOS
Enter the pressure value for the upper calibration point (container full).
→ See also Full calib./HIGH_LEVEL_EASY.
Prerequisite:
• Calibration mode/LEVEL_ADJUST_MODE_EASY = Dry
Factory setting:
Upper range limit (URL) is converted to a unit of height.
Empty pressure/
LOW_LEVEL_PRESSURE_EAS
Y
Entry
Index: 102
Data type: FLOAT
Access: OOS
Enter the pressure value for the lower calibration point (container empty).
→ See also Empty calibration/LOW_LEVEL_EASY.
Prerequisite:
• Calibration mode/LEVEL_ADJUST_MODE_EASY= Dry
Factory setting:
Lower range limit (LRL) is converted to a unit of height.
Electr. delta P/
ELECTRIC_DELTA_P_CONTR
OL
Options
Index: 103
Data type: unsigned8
Access: OOS
For switching the electr. delta P application on or off with an external or
constant value.
Options:
•Off
•External value
• Constant
Factory setting:
Off
E.delta p selec./
E_DELTA_P_INPUT_SELECT
OR
Options
Index: 104
Data type: unsigned8
Access: OOS
Select the input of the Input Selector Block which should be used for the electr.
delta P application.
Options:
•Input 1
•Input 2
•Input 3
•Input 4
Factory setting:
Input 1
E. delta p value/
E_DELTA_P_VALUE
Display
Index: 105
Data type: float
Access: read only
Displays the current input values for electr. delta P.
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
