Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 203
Add. disp. value/
DISPLAY_MAINLINE_2
_CONTENT
Options
Index: 16
Data type: unsigned8
Access: wr for Auto,
OOS
Specify the contents for the second line of the onsite display in the measuring mode.
Options:
•No value
• Pressure
• Main value (%)
•Totalizer 1
•Totalizer 2
The options depend on the measuring mode chosen.
Factory setting:
No value
FF input source/
DISPLAY_INPUT_SELE
CTOR
Options
Index: 17
Data type: unsigned8
Access: wr for Auto,
OOS
Select the input of the Input Selector Block which should be used as the external value
for the display.
Options:
•Input 1
•Input 2
•Input 3
•Input 4
Factory setting:
Input 1
FF input unit/
DISPLAY_INPUT_UNIT
Options
Index: 18
Data type: unsigned16
Access: wr for Auto,
OOS
Select the unit for the external value that should be shown on the display.
Factory setting:
mbar
FF input form./
DISPLAY_INPUT_FOR
MAT
Options
Index: 19
Data type: unsigned8
Access: wr for Auto,
OOS
Select the format for the external value that should be shown on the display.
Options:
•x.x
•x.xx
•x.xxx
•x.xxxx
• x.xxxxx
Factory setting:
x.x
Device name str./
GENERIC_DEVICE_TYP
E
Display
Index: 20
Data type: unsigned8
Access: read only
Displays the device type (Cerabar M, Deltabar M or Deltapilot M).
Display Transducer Block
Parameter Description
