Endress+Hauser Cerabar M - Page 204

Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
204 Endress+Hauser
Diagnostic Transducer Block
Measuring mode/
OPERATING_MODE
Display
Index: 21
Data type: unsigned8
Access: read only
Select the measuring mode.
The operating menu is structured differently depending on the measuring mode
selected.
If the measuring mode is changed, no conversion takes place. If necessary, the device
has to be recalibrated after the measuring mode has been changed.
Options:
• Pressure
•Level
•Flow
Factory setting:
Pressure
Diagnostic Transducer Block
Parameter Description
Device dialog/DEVICE DIALOG
Display
Index: 10
Data type: unsigned8
Access: read only
If configuration is unsuitable, this parameter displays a message indicating that
a configuration error is present. The message can indicate which parameter was
incorrectly configured.
Operator code/S_W_LOCK
Options
Index: 11
Data type: unsigned16
Access: wr for Auto, OOS
Use this function to enter a code to lock or unlock operation.
Options:
•To lock: Enter a number  the release code.
• To unlock: Enter the release code.
The release code is "0" in the order configuration. Another release code can be
defined in the Code definition/USER_S_W_UNLOCK parameter. If the user has
forgotten the release code, it can be made visible again by entering the number
sequence "5864".
Factory setting:
0
Lockstate/STATUS_LOCKING
Display
Index: 12
Data type: unsigned8
Access: read only
Displays the current locking status of the device or conditions that can lock the
device (hardware locking, software locking).
DIP switch/
SWITCH_STATUS_LIST
Display
Index: 13
Data type: unsigned8
Access: read only
Displays the DIP switches activated on the electronic insert.
• P1/P2 switch (Deltabar, inputs inversion enabled)
•Lin/sq. switch (Deltabar, flow has been enabled)
• Simulation switch (AI simulation enabled)
• Damping switch (damping enabled)
• HW lock. switch (HW locking enabled)
Display Transducer Block
Parameter Description
