Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 205
Simulation mode/
SIMULATION_MODE
Options
Index: 14
Data type: unsigned8
Access: OOS
Switch on simulation and select the simulation mode.
Any simulation running is switched off if the measuring mode or level mode
(Lin. mode (037)) is changed.
Options:
•None
• Pressure
• Flow (only differential pressure transmitter)
•Level
•Tank content
• Alarm/warning
Cerabar M /
Deltapilot M
Transducer Block Sensor

Sensor trim

Position
adjustment
Simulation value
Pressure
Damping

Electr. Delta P

P
Pressure Level  Simulation value:
- Level
- Tank content

 PV

Analog Input Block
Deltabar M
Transducer Block Sensor

Sensor trim

Position
adjustment
Simulation value
Pressure
Damping

P
Pressure Level  Simulation value:
- Level
- Tank content
 Flow  Simulation value:
- Flow
Diagnostic Transducer Block
Parameter Description
