Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
206 Endress+Hauser

 PV

Analog Input Block
Simulation unit/
SIMULATION_UNIT
Display
Index: 15
Data type:
Access: read only
Displays the unit of the simulation value (depends on the measuring mode
selected).
Simulated Value/
SIMULATED_VALUE
Entry
Index: 16
Data type: float
Access: OOS
Enter the simulation value.
Prerequisite:
• Simulation/SIMULATION_MODE = Pressure, flow (Deltabar), level or tank
content.
Sim. error no./
ALARM_SIMULATION_VALU
E
Entry
Index: 17
Data type: unsigned16
Access: OOS
Enter the message number for simulation.
See also these Operating Instructions, Section 11.1 "Messages", "Code" table
column.
Prerequisite:
• Simulate/SIMULATE = Alarm/warning
Value when switched on:
485 "Simulation value" (simulation active)
Status/DEVICE_STATUS
Display
Index: 18
Data type: unsigned8
Access: read only
Provides information on the current status of the device.
Diagnostic code/
ACTUAL_HIGHEST_ALARM
Display
Index: 19
Data type: unsigned16
Access: read only
Displays the highest active warning/error message.
Instructions/
ACTUAL_MAINTENANCE_IN
STRUCT
Display
Index: 20
Data type: unsigned16
Access: read only
Instructions for resolving the highest active warning/error message.
Last diag. code/
LAST_ALARM_INFO_IO
Display
Index: 21
Data type: unsigned16
Access: read only
Last rectified error message. Equivalent to the first entry in the Last diag. code
table (logbook).
Diagnostic Transducer Block
Parameter Description
