Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
210 Endress+Hauser
Simulate/SIMULATE
Entry, display
Index: 9
Data type: DS-82
Access: auto, man, OOS
The Simulate/SIMULATE parameter is a structured parameter consisting of five
elements. As the value and status specified here run through the complete algorithm,
the behavior of the Analog Input Block can be checked.
SIMULATE_STATUS
• Enter the status for simulation.
SIMULATE_STATUS
• Enter the simulation value.
TRANSDUCER_STATUS
• Displays the current status of the Transducer Block which is linked to the Analog
Input Block via the Channel/CHANNEL parameter.
TRANSDUCER_VALUE
• Displays the current process value of the Transducer Block, which is linked to the
Analog Input Block via the Channel/CHANNEL parameter.
ENABLE_DISABLE
• Switch the simulation mode on and off.
The "Simulation" DIP switch on the electronic insert must be set to "On".
Factory setting:
Simulation disabled (simulation mode not active)
Transducer Scale/
XD_SCALE
Entry, selection
Index: 10
Data type: DS-68
Access: man, OOS
The Transducer Scale/XD_SCALE parameter is a structured parameter consisting of
four elements.
EU_100:
• Enter the upper limit for the input value of the Analog Input Block.
• Factory setting: 100
EU_0:
• Enter the lower limit for the input value of the Analog Input Block.
• Factory setting: 0
UNITS_INDEX:
• Select the unit.
• Factory setting: %
DECIMAL:
• Displays the number of places after the decimal point for the input value.
• Factory setting: 2
• The Transducer Scale/XD_SCALE parameter corresponds to the Primary Value
Range/PRIMARY_VALUE_ RANGE parameter ( ä 178) in the Transducer Block.
• If the "Direct" option was selected via the Linearization Type/L_TYPE parameter, the
settings for the Transducer Scale/XD_SCALE and Output Scale/OUT_SCALE
parameters must be identical. If this is not the case, the block goes to the OOS mode
and the "Block config error" message is displayed in the Block Error/BLOCK_ERR
parameter.
Analog Input Block
Parameter Description
