Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 211
Output Scale/
OUT_SCALE
Entry, display
Index: 11
Data type: DS-68
Access: auto, man, OOS
The Output Scale/OUT_SCALE parameter is a structured parameter consisting of four
elements.
EU_100:
• Enter the upper limit for the output value of the AI Block OUT ( ä 209).
• Factory setting: 100
EU_0:
• Enter the lower limit for the output value of the AI Block OUT.
• Factory setting: 0
UNITS_INDEX:
• Select the unit.
• Factory setting: %
DECIMAL:
• Displays the number of places after the decimal point for the OUT output value.
• Factory setting: 2
• The OUT output value is also transmitted if it is outside the scaling range. The status
changes to BAD.
• If the "Direct" option was selected via the Linearization Type/L_TYPE parameter, the
settings for the Transducer Scale/XD_SCALE and Output Scale/OUT_SCALE
parameters must be identical. If this is not the case, the block goes to the OOS mode
and the "Block config error" message is displayed in the Block Error/BLOCK_ERR
parameter.
Grant Deny/
GRANT_DENY
Options
Index: 12
Data type: DS-70
Access: auto, man, OOS
Grant or restrict access authorization for a fieldbus host system to the device. This
parameter is not evaluated by Deltabar M, Cerabar M and Deltapilot M.
I/O Options/
IO_OPTS
Options
Index: 13
Data type: bit string
Access: OOS
Activate options for processing the input and output values of the function block.
Factory setting:
No option activated
Status Options/
STATUS_OPTS
Options
Index: 14
Data type: bit string
Access: OOS
Specify status processing and processing of the Output/OUT output parameter.
Factory setting:
No options active
Channel/CHANNEL
Options
Index: 15
Data type:
Access: OOS
Assign the output variables (process variables) of the "Pressure" or "Totalizer"
Transducer Blocks to an Analog Input Block as the input value.
Possibilities
• 1: Primary value from the Pressure Transducer Block - a pressure, level or flow value
depending on the measuring mode selected
• 2: Secondary value from the Pressure Transducer Block, here the sensor
temperature
• 6: Totalizer 1 from the DP_Flow Transducer Block
Factory setting:
• Analog Input Block 1: Channel/CHANNEL = 1: Primary value (pressure measured
value)
• Analog Input Block 2: Channel/CHANNEL = 2: Secondary value (sensor
temperature)
• Analog Input Block 3: Channel/CHANNEL = 6: Totalizer 1
Analog Input Block
Parameter Description
