Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
202 Endress+Hauser
Display Transducer Block
Display Transducer Block
Parameter Description
Device dialog/
DEVICE DIALOG
Display
Index: 10
Data type: unsigned8
Access: read only
If configuration is unsuitable, this parameter displays a message indicating that a
configuration error is present. The message can indicate which parameter was
incorrectly configured.
Operator code/
S_W_LOCK
Options
Index: 11
Data type: unsigned16
Access: wr for Auto,
OOS
Use this function to enter a code to lock or unlock operation.
Options:
•To lock: Enter a number  the release code.
• To unlock: Enter the release code.
The release code is "0" in the order configuration. Another release code can be defined
in the Code definition/USER_S_W_UNLOCK parameter. If the user has forgotten the
release code, it can be made visible again by entering the number sequence "5864".
Factory setting:
0
Lockstate/
STATUS_LOCKING
Display
Index: 12
Data type: unsigned8
Access: read only
Displays the current locking status of the device or conditions that can lock the device
(hardware locking, software locking).
Format 1st value/
AUTOMATIC_MAIN_LI
NE_FORMAT
Options
Index: 13
Data type: unsigned8
Access: wr for Auto,
OOS
Displays the number of decimal places.
Options:
•x.x
•x.xx
•x.xxx
•x.xxxx
• x.xxxxx
Language/
DISPLAY_LANGUAGE
Options
Index: 14
Data type: unsigned8
Access: wr for Auto,
OOS
Select the menu language for the onsite display.
Options:
•English
•Deutsch
•Français
•Español
• Katakana
•Chinese
Factory setting:
English
Display mode/
DISPLAY_MAIN_LINE_
1_CONTENT
Options
Index: 15
Data type: unsigned8
Access: wr for Auto,
OOS
Specify the contents for the first line of the onsite display in the measuring mode.
Options:
• Primary value (PV)
•External value
•All alternating
Factory setting:
Primary value (PV)
