Cerabar M, Deltabar M, Deltapilot M Operation
Endress+Hauser 61
Block configuration when device is delivered
The block model shown below illustrates the block configuration when the device is
delivered.
A0030397
Fig. 27: Block configuration when device is delivered
The Pressure Transducer Block supplies the primary value depending on the measuring
mode, and a secondary value
• for Cerabar/Deltapilot, secondary value = sensor temperature.
• for Deltabar, secondary value = Measured pressure.
By means of the Channel/CHANNEL parameter, the measured values (primary value,
secondary value, etc.) are transferred to an Analog Input Block from the Transducer Block,
see also the following section).
The Discrete Output, PID, Arithmetic, Signal Characterizer and Input Selector Block are not
connected in the as-delivered state (IT, DI).
Deltabar M:
In the DP_FLOW Transducer Block, the flow is totalized in the "Flow" measuring mode and
output by means of the Totalizer 1/TOTALIZER_1 parameter.
Pressure
Pressure
Transducer Block
Transducer Block
Analog Input Block 1
Analog Input Block 1
CHANNEL = 1
CHANNEL = 1
L_TYPE = Direct
L_TYPE = Direct
Analog Input Block 2
Analog Input Block 2
CHANNEL = 3
CHANNEL = 3
L_TYPE = Direct
L_TYPE = Direct
Display
Display
Transducer Block
Transducer Block
Diagnostic
Diagnostic
Transducer Block
Transducer Block
Primary value
Primary value
Resource Block
Resource Block
Integrator
Integrator
Block
Block
Discrete Input
Discrete Input
Block
Block
PID Block
PID Block
Input Selector
Input Selector
Block
Block
Signal
Signal
Characterizer
Characterizer
Block
Block
Discrete
Discrete
Output Block
Output Block
Arithmetic
Arithmetic
Deltabar M
DP flow Block
Secondary value
Secondary value
Block
Block
Cerabar M / Deltapilot M
Measured variable
Measured variable
Sensor
Sensor
Signal evaluation
Signal evaluation
Display
Display
with scaling
with scaling
