Parameter description (Local operation and FieldCare) Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus
162 Endress+Hauser
DENSITY UNIT (812)
Selection
Select the density unit.
Prerequisite:
• LIN. MEASURAND = Level, CALIBRATION MODE = Dry
• LIN. MEASURAND = % (level), CALIBRATION MODE = Dry
• LIN. MEASURAND = Volume, CALIBRATION MODE = Dry
• LIN. MEASURAND = Mass, CALIBRATION MODE = Dry
Options:
•g/cm
3
•kg/dm
3
•kg/m
3
• US lb/in
3
• US lb/ft
3
Factory setting:
kg/dm
3
ADJUST DENSITY (316)
Entry
Enter the density of the fluid.
Prerequisite:
• LIN. MEASURAND = Level, CALIBRATION MODE = Dry
• LIN. MEASURAND = % (level), CALIBRATION MODE = Dry
• LIN. MEASURAND = Volume, CALIBRATION MODE = Dry
• LIN. MEASURAND = Mass, CALIBRATION MODE = Dry
Factory setting:
1000.0
UNIT VOLUME (313)
Selection
Select the volume unit.
Prerequisite:
• LIN. MEASURAND = Volume
Options:
•l
•hl
•cm
3
•dm
3
•m
3
•m
3
E
3
•ft
•ft
3
E
3
•gal
•Igal
•bbl
•User unit, → see also the following parameter descriptions for CUSTOMER UNIT V
and CUST. UNIT. FACT. V
!
Note!
Following a change in the unit, the digital output value of the Analog Input value OUT
and the local operation or the MEASURED VALUE no longer display the same value.
→ See also parameter descriptions for XD SCALE, OUT SCALE and OUT value.
Factory setting:
m
3
CUSTOMER UNIT V (608)
Entry
Enter text (unit) for customer-specific volume unit.
You can enter a maximum of eight alphanumeric characters here.
→ See also CUST. UNIT. FACT. V
Prerequisite:
• LIN. MEASURAND = Volume, UNIT VOLUME = User unit
!
Note!
Only the first five characters are shown on the local operation. For example, if the
customer-specific unit "crates" was selected, only "crate" would be displayed.
If the unit contains a slash, up to eight characters can be shown on the local operation.
The maximum number of characters in the counter is again limited to five. For example if
the customer-specific unit "crates/m2" was selected, "crate/m2" would be displayed.
FieldCare accepts units with eight characters at most. The slash counts as one character.
Factory setting:
_ _ _ _ _ _ _ _
Table 11: OPERATING MENU → SETTINGS → BASIC SETUP "Level", LEVEL MODE "Linear"
Parameter name Description
