22
© 2017 Energreen Srl
Professional machinery
WEIGHT
The total weight of the RoboMAX machine (without equipment) is:
Tracks Weight (kg)
Rubber 2410
Steel 2640
ENGINE
Make YANMAR Type 4TNV98CT-NEN
No. of cylinders 4 Displacement: 3319 cc
Power 53.7 kW - 75 HP Peak torque 291 Nm @ 1600 rpm
Cooling Liquid Air lter Dry
Exhaust gas stand-
ard
USA EPA Tier 4 Final
EU Stage IV
ELECTRICAL SYSTEM
Operating voltage 12 VDC
Alternator 40 A
Battery 180 Ah
HYDRAULIC SYSTEM
Circuit Pump type No.
Maximum capacity
L/min Bar
Translation
Tandem variable
displacement piston
pump in closed circuit
1 100 each 400
Flail head
Variable displacement
pistons type in closed
circuit
1 109 380
Services Gear pump 1 17 180
TRANSFER SPEED
Forwards Reverse
Speed 1 (Slow) 2 (Fast) 1 (Slow) 2 (Fast)
Km/h 2.5 5.5 2.5 5.5
If the machine is tted with iron tracks you are advised ONLY to work in rst gear otherwise
you risk damaging the track
WARNING:
