ENERGREEN RoboMAX - Replacing the Remote Control (Imprinting)

33
© 2017 Energreen Srl
Professional machinery
GREEN LED
SIGNAL Meaning
Off The transmitting unit is off.
Flashes quickly The transmitting unit is on and there is no radio-electric connection.
Flashes slowly The remote control is activated with a radio-electric connection present.
RED LED
(a)
SIGNAL Meaning
Off The transmitter unit is working properly.
Flashing The battery is running low.
On for 2 seconds
(b)
The transmitter unit is not working properly
Flashes once
(b)
When the transmitter unit lights up, it shows that the STOP button is active
or it is broken.
Flashes twice
(b)
When the transmitter unit lights up, it shows that a digital command or
SAFETY command is active or it is broken.
Flashes three times
(b)
When the transmitter unit lights up it shows that the battery is dead.
Flashes four times
(b)
When the transmitter unit lights up, it shows that an analogue command is
active or it is broken.
(a) -When the red LED comes on it is accompanied by a beep.
(b) – The signal is followed by the transmitter unit turning off.
6.4.4 - REPLACING THE REMOTE CONTROL (IMPRINTING)
The address of the remote control is stored on the internal receiver board n the transmitter unit.
The substitution of the remote control (or the central unit) makes the updating of this code
necessary to be able to resume functioning. This operation called “IMPRINTING” is performed as
listed below:
1. Remove the battery from the new remote control;
2. Press the emergency button (17) of the new remote control;
3. Remove the S-Key from the old remote control and insert it in the new remote control;
4. Insert the battery in the new remote control;
5. Press the START button (12) and hold it down until the green LED goes off.
6. Release the emergency button (17).
7. Connect to the RoboMAX.
If a part of the radio control has to be replaced (receiver and / or transmitter), notify Energreen because
this is a safety component and its components are linked to each other and with the machine. In
addition, the frequency used by the replacement must always comply with the one approved in the
country in which the machine is used.
CAUTION:
