ALARM LED (RED)
The ALARM LED indicates faults in the receiver unit.
ALARM LED
SIGNAL Meaning
Off The receiver unit is working properly.
Flashes once There is an error on outputs SO1 and SO2 congured as STOP outputs.
Flashes twice There is an error on outputs SO1 and SO2 congured as SAFETY outputs.
Flashes three times The is an error on the outputs relative to the direction commands.
On There is a conguration error on outputs SO1 and SO2.
RUN LED (GREEN)
The RUN LED indicates the status of the remote control's communication status with the CAN
network Master node.
RUN LED
SIGNAL Meaning
Off The CAN communication is not active.
Flashing The remote control unit is not sending commands to the CAN network.
Access The remote control unit as a node in the CAN network is working properly.
ERR LED (RED)
The ERR LED indicates the status of the CAN communication.
ERR LED
SIGNAL Meaning
Off The CAN communication is working properly.
Flashing The CAN communication is not working properly.
Access No CAN communication.
