66
© 2017 Energreen Srl
Professional machinery
Unscrew the 12 screws that secure the cover. Screw two M6 screws into the holes on the cover
in order to open it slightly and drain the oil.
• Tighten the M8 screw of the central gear pin and use it as a puller to remove the “solar pin”.
• Once the “solar” pin has been removed, tighten the cover.
• Repeat the same procedure for the other gear motor.
WARNING :
• Take care not to allow dirt to get into the gear unit.
• Fill the wheel gear units with oil as soon as the RoboMAX has been moved to a suitable
position in order not to damage them.
