enphase IQ Combiner 5C Quick Install Guide

Tools/additional
items required
S. NO ITEM NAME DESCRIPTION QUANTITY SOURCE
SCENARIO :
SOLAR ONLY
SCENARIO :
SOLAR +
BATTERY
WITHOUT
BACKUP
SCENARIO :
SOLAR +
BATTERY
WITH
BACKUP
SCENARIO :
SUNLIGHT
BACKUP
1
Control cable
(CTRL-SC3-NA-01)
For Control
Communication between
Enphase products
Per site
requirement
Provided by
Enphase
No Yes Yes Yes
2 Copper conductors
To connect IQCombiner
main lugs to the breaker
in the load center or
IQSystem Controller
Per site
requirement
Retail outlets Yes Yes Yes Yes
3 DER breakers
20 A breaker for PV
branch circuits (or) 20
A/40 A/60 A breaker
for IQBattery
Based on PV
and IQBattery
system size
Enphase SKU
(separately
orderable) or
retail outlets
Yes Yes Yes Yes
4
Breaker in the
load center/
IQSystemController
Appropriately size breaker
for installing IQCombiner
in main load center or
IQSystemController
1
Provided by
Enphase /
Retail outlets
No Yes Yes Yes
5 Screwdriver
To insert, remove &
tighten screws
1 Retail outlets Yes Yes Yes Yes
6 Plier To twist and cut wires 1 Retail outlets Yes Yes Yes Yes
7 Torque wrench
To control and apply
a specic torque
to a fastener
1 Retail outlets Yes Yes Yes Yes
8 #8 screws
For mounting
IQCombiner on the wall
2 Retail outlets Yes Yes Yes Yes
9 Rain-tight conduit hubs
For wire entry/exit from
the IQCombiner
Per site
requirement
Retail outlets Yes Yes Yes Yes
10 Step drill
To drill conduit in
the IQCombiner
Per site
requirement
Retail outlets Yes Yes Yes Yes
IQ Combiner 5/5C Quick Install Guide 10
