enphase IQ Combiner 5C Quick Install Guide

ENPHASE BREAKERS
OFF-THE-SHELF
BREAKERS
USED FOR
SCENARIO :
SOLAR ONLY
SCENARIO :
SOLAR + BATTERY
WITHOUT BACKUP
SCENARIO :
SOLAR + BATTERY
WITH BACKUP
SCENARIO :
SUNLIGHT BACKUP
BRK-20A-2P-240V
Eaton BR220, Siemens
Q220, ABB THQL 2120
PV branch circuits,
IQBattery
Yes Yes Yes Yes
BRK-20A-2P-240V-B Eaton BR220B
PV branch circuits,
IQBattery
No* No* No* No*
BRK-40A-2P-240V
Eaton BR240, Siemens
Q240, ABB THQL 2140
IQBattery Yes Yes No No
BRK-40A-2P-240V-B Eaton BR240B IQBattery No* No* No No
BRK-60A-2P-240V
Eaton BR260, Siemens
Q260, ABB THQL 2160
IQBattery Yes Yes No No
DER Breakers
IQ Combiner 5/5C Quick Install Guide11
* Can be used but is not necessary
NOTE: For scenarios with backup, IQ Battery breakers with a rating >= 40
Amp will be housed in the IQ System Controller.
X-IQ-AM1-240-5-HDK or X-IQ-AM1-240-5C-HDK (IQ Combiner 5/5C with hold-down kit)
ENPHASE BREAKERS
OFF-THE-SHELF
BREAKERS
USED FOR
SCENARIO :
SOLAR ONLY
SCENARIO :
SOLAR + BATTERY
WITHOUT BACKUP
SCENARIO :
SOLAR + BATTERY
WITH BACKUP
SCENARIO :
SUNLIGHT BACKUP
BRK-20A-2P-240V
Eaton BR220, Siemens
Q220, ABB THQL 2120
PV branch circuits,
IQBattery
Yes Yes No No
BRK-20A-2P-240V-B Eaton BR220B
PV branch circuits,
IQBattery
No* No* Yes Yes
BRK-40A-2P-240V
Eaton BR240, Siemens
Q240, ABB THQL 2140
IQBattery Yes Yes No No
BRK-40A-2P-240V-B Eaton BR240B IQBattery No* No* No No
BRK-60A-2P-240V
Eaton BR260, Siemens
Q260, ABB THQL 2160
IQBattery Yes Yes No No
X-IQ-AM1-240-5 or X-IQ-AM1-240-5C (IQ Combiner 5/5C without hold-down kit)
