enphase IQ Combiner 5C Quick Install Guide

Home Loads
AC Power Line
PLC Over AC Line
Main load
center
Utility Meter
Wh
IQ Combiner 5/5C
IQ6/IQ7 or IQ8
Microinverter
Grid
System
congurations
Based on the customer's requirement, the IQCombiner can be
installed in multiple site congurations. These can be classied into
four scenarios:
1. Solar Only
2. Solar + Battery without backup
3. Solar + Battery with backup
4. Sunlight Backup
Scenario 1:
Solar Only
This is the preferred conguration when homeowners want to
minimize their utility bills and reduce their carbon footprint without
requiring backup. Due to the Enphase system’s modular design,
homeowners have the option to start with this conguration and
upgrade to storage later.
The microinverter ranges supported in this conguration are IQ6,
IQ7, and IQ8.
NOTE: IQ6 and IQ7 cannot be used in the same PV array with IQ8
series microinverters.
IQ Combiner 5/5C Quick Install Guide5
