enphase IQ Combiner 5C Quick Install Guide

The IQCombiner5/5C consolidates interconnection equipment
into a single enclosure and streamlines IQSeries Microinverters
and IQGateway installation by providing a consistent, pre-wired
solution for residential applications. IQCombiner5/5C uses wired
communication and is compatible with IQSystemController3/3G
and IQBattery5P.
SMART EASY TO INSTALL RELIABLE
Includes IQGateway for
communication and control
Mounts to one stud with centered brackets Durable NRTL-certied NEMA type 3R enclosure
Includes Enphase Mobile Connect
(CELLMODEM-M1-06-SP-05),
only with IQCombiner5C
Supports bottom, back, and side conduit entries Five-year limited warranty
Supports exible networking:
Wi-Fi, Ethernet, or cellular
Supports up to four 2-pole branch circuits for
240 VAC plug-in breakers (not included)
Two-years labor reimbursement program
coverage included for both the IQCombiner SKUs
Provides production metering
(revenue grade), consumption metering,
and IQBattery5P metering.
80 A total PV branch circuits UL1741 Listed
Compatibility: TheIQCombiner5/5C is compatible with IQ6/IQ7 or
IQ8 Microinverters, IQBattery5P, and IQSystemController3/3G.
It requires aCOMMS-KIT-01for compatibility with
IQBattery3/10/3T/10T and IQSystemController1/2. It is not
compatible with M Series Microinverters.
Risk of equipment damage. Instructions for wiring grid-forming
systems are dierent from grid-tied systems. Follow specic
wiring instructions as outlined herein to maintain the warranty.
NOTE: IQCombiner5/5C can be used for grid-interactive
(i.e., grid-tied) as well as multi-mode (i.e., grid-forming) installations.
IQ Combiner 5/5C Quick Install Guide 2
NOTE: The X-IQ-AM1-240-5-HDK & X-IQ-AM1-240-5C-HDK SKUs
will be available for orders by Q1 2024.
