3.4.3. Button Functions
In addition to their main functions, the 5 buttons on the front panel can be used as shortcut buttons
for easily reaching screens. Button functions descriptions below.
ESC button (9) : It has 3 main functions:
• Exiting from any menu is done by pressing ESC button
• While on measuring screen: As seen on the symbols (V I F) above the button, it is used to monitor
between voltage, current and frequency measurement screens.
• As seen on the symbols (Event) below the button, event screen is reached when pressed for 3
seconds
BACK Button (10) : It has 3 main functions:
• While on measuring screen: As seen on the symbols (P PF) above the button, it is used
to navigate between active power, reactive power, apparent power, power factor and Cos φ
measurement screens.
• It is used to select the previous digit while entering a numerical value in the menu or to return
to the previous menu level.
• As seen on the symbols (Test) below the button, connection control is reached when pressed
for 3 seconds.
Down Button (11) : It has 2 main functions:
• While on measuring screen: As seen on the symbols (E Clock) above the button, it is used to
navigate between import/export active energy consumption, reactive energy consumption,
tari and time information screens.
• While on menu screens: It is used to navigate between menu options and to decrease a value
to be adjusted.
Up Button (12) : It has 2 main functions:
• While on measuring screen: As seen on the symbols (THD H) above the button, it is used to
navigate between THDV, THDI and individual harmonic measurement screens.
• While on menu screens: It is used to navigate between menu options and to increase a value
to be adjusted.
SET Button (13) : It has 3 main functions:
• It enables access to menu screens when pressed for 3 seconds. When the PIN is active, a
password is asked before entering the menu. After the correct password is entered, access to
menu is allowed.
• It is used to reach the desired adjustment screen and to save the changed settings. Pressing
the button is enough for this operation.
• While on measuring screen: It is used to navigate between Min, Max, Demand and Maximum
Demand screens.
