44
To connect the pulse oximeter:
1. Connect the plug of the pulse oximeter to the SpO2 (pulse oximeter) connector at the rear of
the device.
2. Attach to patient.
To remove the cable, pull firmly on the locking ring. Do not twist.
NOTE:
In order to display the SP02 measurements and to set the alarms, activate SP02
monitoring in the Patient/Circuit configuration menu.
Attaching a remote alarm
A remote alarm can be connected to the EO-150 ventilator with the Remote Alarm Cable Accessory.
This alarm alerts you to an event that requires immediate attention. An audible and visual alarm is
triggered when an alarm is activated on the ventilator. For full instructions on using the Remote Alarm,
see the Remote Alarm User Guide.
Attaching EO-BAT9
Please, refer to the EO-BAT9 user guide.
