Mounting EO150 on trolley (KC072283)
When using the trolley in combination with EO150 and other accessories, always
verify a maximum weight of 20 kg is not exceeded.
Always use the handle to move the trolley (always pull, do not push).
Not respecting this could result in damaging the ventilator or causing patient injury.
The EO-150 ventilator must be mounted on the trolley KC072283 according to the following:
1 – insert the device on the trolley columns
2 – Fix the device on the trolley with bottom screw
3 - Insertion of the arm
Insert the arm inside the dedicated trolley port and secure with screw.
4 - Insertion of humidifier
Insert the humidifier inside the dedicated trolley port.
Use only screws delivered by Eove. Otherwise there is a risk to damage the
its accessories.
