65
(A)VCV: Volume Assisted Controlled ventilation (Valve)
This mode delivers breaths according to the set volume (VT), based on a flow control (Rectangle or
Decelerated Flow Ramp). Inspiration lasts a set constant time (I Time). Exhalation controls the set
exhalation pressure (PEEP). Breaths are guaranteed at a set minimum rate (Rate). Patient can increase
rate by inspiration triggering (I Trig.).
Setting Adult Pediatric Limitations
VT (ml) 300-2500 30-600 None
PEEP (mb) OFF / 1-25 OFF / 1-20 None
Flow Ramp 1 (Rectangle), 2 (Decelerating) None
Rate (c/min) 5-60 5-80 Rate ≤ 45 / I Time (I/E ≤ 3/1)*
I Time (s) 0.3-2.5 0.3-2.5 Rate ≤ 45 / I Time (I/E ≤ 3/1)*
I Trig. OFF / AUTO / 1-5 OFF / AUTO / 1-5 None
*A cancellable alarm “Reversed I/E” will trigger when the set I/E ratio exceeds 1/1
(A)PCV: Pressure Assisted Controlled Ventilation (Valve)
This mode delivers breaths according to the set total pressure, Pres. Sup. added to the set exhalation
pressure (PEEP). Inspiration lasts a set constant time (I Time). Breaths are guaranteed at a set
minimum rate (Rate). Patient can increase rate by inspiration triggering (I Trig.). An optional Vt Target
can be activated.
Setting Adult Pediatric Limitations
Pres. Control.
5-48 5-48 Pres. Control. + PEEP ≤ 49 mb
Pres. Control. < P. Contr. Max
PEEP (mb) OFF / 1-25 OFF / 1-20 Pres. Control. + PEEP ≤ 49 mb
P. Contr. Max + PEEP ≤ 50 mb
Pres. Ramp 1-5 (100-500ms) 1-5 (50-250ms) None
Rate (c/min) 5-60 5-80 Rate ≤ 45 / I Time (I/E ≤
3/1)*
I Time (s) 0.3-2.5 0.3-2.5 Rate ≤ 45 / I Time (I/E ≤
3/1)*
I Trig. OFF / AUTO / 1-5 OFF / AUTO / 1-5 None
Vt Target (ml) OFF / 300-2500 OFF / 30-600 None
P. Contr. Max (mb) 10-49 10-49 Inactive when Vt Target is OFF
P. Contr. Max + PEEP ≤ 50 mb
Pres. Control. < P. Contr. Max
Target Speed 1-3 1-3 Inactive when Vt Target is OFF
*A cancellable alarm “Reversed I/E” will trigger when the set I/E ratio exceeds 1/1
PSV: Pressure Support Ventilation (Valve)
This mode delivers breaths according to the set total pressure, (Pres. Sup.) added to the set exhalation
pressure (PEEP). Inspiration time is variable adapting to patient flow (E Trig.). Breaths are guaranteed
at a set minimum rate (Rate). Patient can increase rate by inspiration triggering (I Trig.).
During backup breaths, the set Backup I Time defines the inspiration time. If set to AUTO, E trig. still
applies to backup breaths. E Trig. is allowed between I Time Min and I Time Max.
