Section 8: Using the Front Control Panel
125
Config
The Config key takes you into the factory settings that do not normally need to be
reset by the end user. These functions are listed below.
To access and move from one Config setting to another use the following
instructions:
1. Press the Config key – Config Menu: will appear on the keyboard display.
2. Press the Focus key to scroll through the different menu items.
3. Once you reach the menu item you are looking for use the Up or Down cursor
keys to change the value of the item. Press and release the Up or Down keys to
change the settings by one unit. Press and hold the Up or Down keys to produce
a rapid change of the setting.
4. The numerical range of adjustment is shown in the table below. Each single
digit change is equal to a half thousandth of an inch - .0005” (0.00125 mm)
(except the Laser and Stamp Match values, which are in pixels). For example,
changing the X-Home position value from 350 to 395 would move the X-Home
position 0.0225 inches (0.55 mm) to the right.
5. Because the adjustment increments are so small it may be easier to think of the
change as a two digit change is equal to 0.001 inch.
CONFIG SETTINGS
RANGE
X - Home: Range: +999 to -999
Increasing this value will move
X-Home to the left.
Y - Home: Range: -100 to +999
Increasing this value will move
Y-Home up.
Laser Match: Range: -20 to +20
Establishes the left to right vertical
alignment of alternating raster lines.
Stamp Match: Range: -20 to +20
Establishes the left to right vertical
alignment of alternating raster lines for
stamp mode.
Sys Unit: Range: Inch or mm
Set the units of operation in the laser system
to Inches or mm.
