4.4 Installation Set
Displays values on the counters of the printer and sets.
4.4.1 Executing Installation Set
1) Turn off the power.
2) Turn on the power while holding down "S" and "T" keys.
3) Release the fingers from these keys when the "CE Mode" and "Password" is displayed.
4) Press "T" key twice and press "OK" key.
5) The "CE Mode" and "ESS Diag" are displayed. (Entered the Diag. mode.)
6) Press "T" to select “Installation Set”, and then press "OK" key.
7) Press "S" and "T" key to select the item.
8) Press "OK" key twice to execute the setting.
To exit the Print or to return to one step higher menu, press the "STOP" key.
Menu Contents Setting value
Serial No. Serial number of the printer. Read only
Tone Correction Specifies whether or not tone correction is performed.
On: Enable
Off: Disable
HexDup
Allows you to print the received print data in hexadecimal
notation.
Used to analyze the received data in case of a printing error.
Setting Hex Dump to ON allows you to print the received
data via [Info Page] under [Print info].
On: Enable
Off: Disable
Pixel Counter Pixel count values of colors Y/M/C/K. Read only
Configuration
The use of "Configuration" is prohibited since it is a tool for
design development.
-
Print Counter
Displays the respective counter values in the master NVM
and backup NVM.
Read only
Print
Service
Full Color: Number of color print.
B/W: Number of the black and white print.
Total: Total of Full Color, Color 1, Color 2 and B/W.
Full Color Error: Number of error in color print.
B/W Error: Number of error in black and white
print.
CopyCounter
MtoB
Copies the counter value in the master NVM of the ESS
PWBA to the backup NVM of the ESS PWBA.
-
CopyCounter
BtoM
Copies the counter value in the backup NVM of the ESS
PWBA to the master NVM of the ESS PWBA.
-
Clear All NVM Initializes all value of NVM. -
Clear JobHistory Initializes Job history. -
Clear AuditronPV
Initializes print volume (PV) or information of Print Auditron.
When Print Auditron is enabled, initializes information of
Print Auditron.
-
