Chapter 6 Principles of Operation
Epson AcuLaser C2900N
Revision B
Confidential
1.2 Schematic Diagram for Printing Processes
Outline of printing processes is shown in the figure below.
MiS06002SA
ROS
[(2)Exposure]
Drum Cartridge
[(1)Charge]
[(3)Development]
[(4)Transfer]
[(5)Cleaning]
FUSER UNIT
[(6)Fusing]
Transfer ASSY
[(4)Transfer]
[(7)Cleaning]
:
Laser beam
: Paper transfer
