4 - 3
Chapter 4 Plug/Jack (P/J) Connector Locations
Epson AcuLaser C2900N
Revision B
Confidential
Option Duplex
Option Feeder
P/J Coordinates Remarks
272 I-169
Connects FEEDER ASSY DUP SFP STD (HARNESS ASSY DUP) and
PRINTER
601 E-169 Connects PWBA DUP and HARNESS ASSY DUP
602 D-168 Connects PWBA DUP and DRIVE ASSY EXIT (Exit Motor)
603 D-168 Connects PWBA DUP and DRIVE ASSY DUP (DUP Motor)
604 E-168 Connects PWBA DUP and DRIVE ASSY EXIT (DUP Clutch)
605 E-169 Not Connect
P/J Coordinates Remarks
273 D-184 Connects 250 OPTION FEEDER (HARNESS ASSY TRAY) and PRINTER
419 C-179 Connects PWBA FEED H and HARNESS ASSY TRAY
420 D-179 Connects PWBA FEED H and HARNESS ASSY TRAY COMP
421 C-180 Connects PWBA FEED H and HARNESS ASSY TRAY COMP
422 D-180 Connects PWBA FEED H and HARNESS ASSY TRAY MOT
4201 H-181 Connects Turn Clutch and HARNESS ASSY TRAY COMP
4202 D-185 Connects Paper Paht Senser and HARNESS ASSY TRAY COMP
4211 F-180 Connects Feed Solenoid and HARNESS ASSY TRAY COMP
4212 F-185 Connects Tray2 No PaperSenser and HARNESS ASSY TRAY COMP
4221 E-179
Connects MOTOR ASSY SUB (OPT FDR Motor) and HARNESS ASSY
TRAY MOT
