3.8.2.3 Fax Function Check by [Method C] and External
Connection Function Check
SETTING METHOD
CHECK PROCEDURE
[Sender: “R” unit => Receiver: “G” unit]
1. Set test chart on the document glass of “R” unit.
2. Enter fax mode by pushing fax button.
3. Input fax number of “G” unit on “R” unit. (Regarding FAX number, refer to
the telephone line simulator’s manual.)
4. Push “Start” button in “B&W” mode.
5. Push “Back” button after being displayed as “Send another page?” on LCD
panel to send fax data from “R” unit to “G” unit.
[Sender: “G” unit => Receiver: “R” unit]
1. Set test chart on the document glass of “G” unit.
2. Enter fax mode by pushing fax button.
3. Input fax number of “R” unit on “G” unit. (Regarding FAX number, refer to
the telephone line simulator’s manual.)
4. Push “Start” button in “B&W” mode.
5. Push “Back” button after being displayed as “Send another page?” on LCD
panel to send fax data from “G” unit to “R” unit.
6. Confirm if telephone rings correctly during calling tone of “R” unit rings.
7. Confirm if dial tone of telephone is lost during “R” unit receives fax data
without calling tone.
CHECK POINT OF “R” UNIT
Telephone
EXT port
Line port
Repaired/refurbished
Epson Artisan 800/Epson
Stylus Photo PX800FW/
TX800FW
Fax cable
Fax cable
Fax cable
*Repaired/refurbished Epson Artisan 800/
Epson Stylus Photo PX800FW/
TX800FW is represented by “R” unit
from this.
*Refer to Table 3-37 on page 87 for default
setting.
*Guaranteed unit means FAX function and EXT
port perform correctly.
Guaranteed Epson Artisan 800/Epson Stylus
Photo PX800FW/TX800FW is represented by
“G” unit from this.
PBX
Guaranteed unit
Checked
Function
Check Timing Check Point
Fax Function
After sending of fax data
Make sure that “R” unit sends fax data
correctly.
After receiving of fax
data
Make sure that “R” unit receives fax data
correctly.
External
Connection (EXT
port) Function
During calling of fax
(Step 6)
Check if you can hear ringing tone from
telephone before receiving fax. In this
case, the telephone sounds ringing.
During receiving fax data
(Step 7)
Check if you can't hear dial tone from the
telephone during receiving fax data. In this
case, the telephone doesn't sound dial tone.
