Epson EB-485W User Manual

a
• If you set Standby Mode to Communication On, you can output images to an external monitor even if the projector is in standby mode. You can also output
audio to an external speaker. Audio input from the HDMI port, USB-A port, USB-B port, or the LAN port cannot be output.
s Extended - Standby Setup - Standby Mode p.103
• Only analog RGB signals from the Computer1 port can be output to an external monitor. You cannot output signals input from other ports or component video
signals.
• Setting gauges for functions such as Keystone, Configuration menu, or Help screens are not output to the external monitor.
• When the audio cable jack is inserted into the Audio Out port, audio stops being output from the projector's built-in speakers and switches to external
output.
Connecting Equipment
35
http://www.pureglare.com.au

Epson EB-485W Specifications

General

Focus	Manual
Offset	5.8 %
Focal length range	0 - 3.71 mm
Matrix size	0.59 \
White light output	3100 ANSI lumens
Native aspect ratio	16:10
Projection distance	0 - 0.43 m
Projection technology	3LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	60 - 100 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-5 - 5 °
Projector brightness (economic mode)	1800 ANSI lumens
Lamp type	UHE
Lamp power	215 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Analog signal format system	-
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	35 dB
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	0.27 W
Power consumption (typical)	300 W

Weight and Dimensions

Weight	5200 g
