Epson EB-485W User Manual

c
Computer images are projected.
It may take a while for computer images to be projected. Until the
computer images are projected, leave the equipment as is and do not
disconnect the USB cable or turn off the power of the projector.
d
Disconnect the USB cable when you are finished.
When disconnecting the USB cable, there is no need to use Safely
Remove Hardware.
a
• If it is not installed automatically, double-click My Computer
- EPSON_PJ_UD - EMP_UDSE.EXE on your computer.
• If nothing is projected for some reason, click All Programs -
EPSON Projector - Epson USB Display - Epson USB
Display Vx.xx on your computer.
• When using a computer running Windows 2000 under user
authority, a Windows error message is displayed and you may
not be able to use the software. In this case, try updating
Windows to the latest version, restart, and then try to connect
again.
For more details, contact your local dealer or the nearest
address provided in the following document.
s Epson Projector Contact List
For Mac OS X
a
Connect the computer's USB port to the projector's USB-B port
using the supplied or a commercially available USB cable.
The Setup folder of USB Display is displayed in the Finder.
b
Double-click the USB Display Installer icon.
c
Follow the on-screen instructions to install.
d
When the License Agreement screen is displayed, click Agree.
Enter the administrator authority password and start the installation.
When the installation is complete, the USB Display icon is displayed
in the Dock and menu bar.
e
Computer images are projected.
It may take a while for computer images to be projected. Until the
computer images are projected, leave the equipment as is and do not
disconnect the USB cable or turn off the power of the projector.
f
When you have finished, select Disconnect from the menu bar or
from the USB Display icon on the Dock. You can then disconnect
the USB cable.
a
• If the USB Display setup folder is not displayed automatically
in the Finder, double-click EPSON PJ_UD - USB Display
Installer on your computer.
• If nothing is projected for some reason, click the USB
Display icon in the Dock.
• If there is no USB Display icon in the Dock, double-click
USB Display from the Applications folder.
• If you select Exit from the USB Display icon menu on the
Dock, USB Display does not start automatically when you
connect the USB cable.
Uninstalling
For Windows 2000
a
Click Start, select Settings, and then click Control Panel.
b
Double-click Add/Remove Programs.
c
Click Change or Remove Programs.
d
Select Epson USB Display and click Change/Remove.
Projecting images
43
http://www.pureglare.com.au

Epson EB-485W Specifications

General

Focus	Manual
Offset	5.8 %
Focal length range	0 - 3.71 mm
Matrix size	0.59 \
White light output	3100 ANSI lumens
Native aspect ratio	16:10
Projection distance	0 - 0.43 m
Projection technology	3LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	60 - 100 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-5 - 5 °
Projector brightness (economic mode)	1800 ANSI lumens
Lamp type	UHE
Lamp power	215 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Analog signal format system	-
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	35 dB
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	0.27 W
Power consumption (typical)	300 W

Weight and Dimensions

Weight	5200 g
