Epson EB-485W User Manual

Adjusting the Horizontal Position of the Image (Models Supplied with the Feet Only)
.......................................................... 50
Correcting the Focus ...........................................50
Adjusting the Volume..........................................50
Selecting the Projection Quality (Selecting Color Mode)...................51
Setting Auto Iris ..............................................52
Changing the Aspect Ratio of the Projected Image.......................52
Changing methods ..........................................53
Changing the aspect mode (EB-485Wi/EB-485W/EB-475Wi/EB-475W only) .....53
Changing the aspect mode (EB-480i/EB-480/EB-470 only)................54
Useful Functions
Easy Interactive Function (EB-485Wi/EB-480i/EB-475Wi only)
........................................................... 57
Introducing the Easy Interactive Function .............................57
Drawing with the projector's built-in function ........................57
Operating as a mouse and drawing by connecting to a computer (Computer
Interactive)................................................ 57
Drawing with the Projector's Built-in Function..........................58
Procedure................................................58
Calibrating the pen ..........................................59
Toolbar functions ...........................................62
Operating as a mouse and drawing by connecting to a computer (Computer
Interactive).................................................. 64
Install Easy Interactive Driver (Mac OS X only)........................64
Operating the computer with a pen instead of a mouse .................65
Allowing two people to use pens at the same time.....................65
Adjusting the pen operation area.................................66
Projection Functions ....................................... 67
Hiding the Image and Sound Temporarily (A/V Mute).....................67
Freezing the Image (Freeze)......................................67
Pointer Function (Pointer)........................................68
Enlarging Part of the Image (E-Zoom)................................69
Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse) . . . . . . 70
Saving a User's Logo ...........................................71
Saving User Pattern ............................................73
Projecting Without a Computer (Slideshow) ...........................74
Specifications for files that can be projected using Slideshow ..............74
Slideshow examples.........................................75
Slideshow operating methods................................... 75
Projecting the selected image ...................................77
Projecting image files in a folder in sequence (Slideshow)................78
Image file display settings and Slideshow operation settings..............78
Security Functions ......................................... 80
Managing Users (Password Protect) .................................80
Kinds of Password Protect......................................80
Setting Password Protect ......................................80
Entering the Password ........................................81
Restricting Operation (Control Panel Lock)............................ 82
Anti-Theft Lock ............................................... 83
Installing the wire lock ........................................83
Monitoring and Controlling ................................ 84
About EasyMP Monitor ..........................................84
Changing Settings Using a Web Browser (Web Control) .................... 84
Projector setup ............................................. 84
Displaying the Web Control screen ...............................85
Displaying the Web Remote screen...............................85
Using the Mail Notification Function to Report Problems................... 87
Reading Error Notification Mail ..................................87
Management Using SNMP .......................................87
ESC/VP21 Commands ........................................... 88
Command list..............................................88
Cable layouts ..............................................88
About PJLink................................................89
About Crestron RoomView
®
......................................90
Operating a projector from your computer ..........................90
Contents
4
http://www.pureglare.com.au

Epson EB-485W Specifications

General

Focus	Manual
Offset	5.8 %
Focal length range	0 - 3.71 mm
Matrix size	0.59 \
White light output	3100 ANSI lumens
Native aspect ratio	16:10
Projection distance	0 - 0.43 m
Projection technology	3LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	60 - 100 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-5 - 5 °
Projector brightness (economic mode)	1800 ANSI lumens
Lamp type	UHE
Lamp power	215 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Analog signal format system	-
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	35 dB
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	0.27 W
Power consumption (typical)	300 W

Weight and Dimensions

Weight	5200 g
