s "Correcting the Focus" p.50
c
Select "Yes".
Use the [
] button on the remote control or control panel to select
"Yes". You cannot select Easy Interactive Pen when performing
operations from the configuration menu.
d
The pattern image is projected and calibration starts.
Wait until calibration is complete.
Do not obstruct the projected light while the pattern image is being
projected.
a
• Select [ ] using Easy Interactive Pen on the toolbar and execute
Auto Calibration if the discrepancy is small.
• However, execute Auto Calibration from the remote control or
control panel when you are calibrating the pen for the first time.
• For pen positioning, do not switch between making operations using
the remote control and making operations using the Easy Interactive
Pen.
If Auto Calibration is unsuccessful, try Manual Calibration.
s
"Manual Calibration" p.60
Manual Calibration
This function allows you to manually calibrate the pen.
a
Set Extended - Easy Interactive Function to Manual Calibration
from the configuration menu.
b
Adjust the focus by following the on-screen instructions.
Easy Interactive Function (EB-485Wi/EB-480i/EB-475Wi only)
60
To Next Page
