a
You can also insert a memory card into a USB card reader and then
connect the reader to the projector. However, some commercially
available USB card readers may not be compatible with the
projector.
If the following screen (Select Drive screen) is displayed, use the
[
], [ ], [ ], and [ ] buttons to select the drive you want to
use, and then press the [
] button.
You can display the Select Drive screen by positioning the cursor on
Select Drive at the top of the file list screen, and then press the [
]
button.
Projecting images
a
Use the [ ], [ ], [ ], and [ ] buttons to select the file or
folder you want to project.
a
If not all of the files and folders are displayed on the current
screen, press the [
]
] button on the remote control, or position
the cursor on Next Page at the bottom of the screen and press
the [
] button.
To return to the previous screen, press the [[] button on the
remote control, or position the cursor on Previous Page at the
top of the screen and press the [
] button.
b
Press the [ ] button.
The selected image is displayed.
When a folder is selected, the files in the selected folder are
displayed. To return to the screen which was displayed before
opening the folder, position the cursor on Back to Top and press the
[
] button.
Rotating images
You can rotate the played images in 90˚ increments. The rotating function
is also available during Slideshow.
Projection Functions
76
http://www.pureglare.com.au

Table of Contents

Other manuals for Epson EB-485W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-485W and is the answer not in the manual?

Epson EB-485W Specifications

General IconGeneral
FocusManual
Offset5.8 %
Focal length range0 - 3.71 mm
Matrix size0.59 \
White light output3100 ANSI lumens
Native aspect ratio16:10
Projection distance0 - 0.43 m
Projection technology3LCD
Contrast ratio (typical)3000:1
Screen size compatibility60 - 100 \
Projector native resolutionWXGA (1280x800)
Keystone correction, horizontal-5 - 5 °
Projector brightness (economic mode)1800 ANSI lumens
Lamp typeUHE
Lamp power215 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)4000 h
Full HDNo
Analog signal format system-
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity3
Ethernet LANYes
Ethernet LAN data rates10, 100 Mbit/s
Noise level35 dB
Noise level (economic mode)28 dB
RMS rated power16 W
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
Power consumption (standby)0.27 W
Power consumption (typical)300 W
Weight and Dimensions IconWeight and Dimensions
Weight5200 g
