Selecting Network Device Display
122
If you have connected devices to the projector via a network, you can select to
project an image from those devices.
You can select the image source from computers that are running Epson
iProjection (Windows/Mac), and smartphones or tablets that are running
Epson iProjection (iOS/Android).
a
You can select any connected network device for projection, even if the
user connected using the Epson iProjection software with the
moderator feature enabled. See the Epson iProjection Operation Guide
(Windows/Mac) for details about the moderator feature.
a
Select the icon on the toolbar, and then select Participant List.
The user selection screen is displayed.
b
Select the user name for the device you want to project from.
A
Displays the user names for network devices connected to the projector.
When displaying thumbnails, each device screen is displayed as a
thumbnail.
The icon is shown next to the user name of the currently projected
device.
B
Switches the display for the user selection screen between thumbnails or
icons.
C
Refreshes the user selection screen.
When an additional user connects to the projector via a network, select
this button to update the user list.
Refreshing information takes a few seconds.
D
Click to move to the previous page or the next page.
E
Closes the user selection screen and returns to the previous screen.
a
On the user selection screen, you can use two pens or one
finger at a time.
