Epson EB-735F User Manual

Projecting Multiple Images Simultaneously
129
gg Related Links
• "Unsupported Input Source Combinations for Split Screen Projection" p.129
• "Split Screen Projection Restrictions" p.129
Unsupported Input Source Combinations for Split
Screen Projection
These input source combinations cannot be projected simultaneously.
• Computer1, Computer2, and Video
• HDMI2 and HDMI3
• USB, USB Display, and LAN
a
When you split the screen into quarters and select the USB input
source, you can select only Screen Mirroring1 or Screen Mirroring2 for
the other input sources.
Split Screen Projection Restrictions
Operating restrictions
The following operations cannot be performed during split screen projection.
• Setting the projector's menu
• E-Zoom
• Switching the aspect mode (the aspect mode is set to Auto)
• Operations using the [User] button on the remote control, other than
displaying the network information on the projected surface.
• Applying the Dynamic Contrast setting
• Displaying the network information on the projected surface by a method
other than pressing the [User] button.
• Displaying the Screen Mirroring information bar
Image restrictions
Even if you set No-signal Screen to Logo in the projector's Display menu, the
blue screen appears when no image signal is being input.
gg Related Links
• "Image Aspect Ratio" p.77
• "Zooming Images" p.143
• "Turning On Automatic Luminance Adjustment" p.82
• "Adjusting the Menu Settings" p.213

Epson EB-735F Specifications

General

Matrix size	0.61 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	- m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 120 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	2500 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	0.26 - 0.36:1
Zoom capability	Yes
Fixed focal length	3.7 mm
3D	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-B ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	36 dB
Country of origin	China
Noise level (economic mode)	26 dB
Cables included	AC
Bundled software	EasyMP Multi PC Projection, Epson Projektor Management
Storage temperature (T-T)	-10 - 60 °C
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	255 W
Power consumption (economy mode)	197 W
Placement	Ceiling, Wall
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
RMS rated power	16 W
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Sustainability certificates	TCO
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Extron, Crestron (RS-232C only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol

Weight and Dimensions

Depth	395 mm
Width	356 mm
Height	133 mm
Weight	5700 g
Package depth	475 mm
Package width	442 mm
Package height	315 mm
Package weight	8209 g
