Projector Placement
28
You can install the projector on a wall or ceiling, or place it on a table to
project images.
To install the projector on a wall, or mount the projector from a ceiling or
vertically on a desk, you can use an optional mount or a commercially
available mount compatible with the VESA Mounting Interface Standard
(100 × 100 mm).
The projector can be installed at various angles without interactive features.
There is no vertical or horizontal limit to how the projector can be installed.
When using interactive features, the projector can be tilted up to 3˚,
regardless of the projector placement (EB‑735Fi/EB‑725Wi).
Note the following points when selecting a projector location:
• Place the projector on a sturdy, level surface or install it using a compatible
mount.
• Leave plenty of space around and under the projector for ventilation, and
do not place it on top of or next to anything that could block the vents.
• Place the projector so it squarely faces the screen, not at an angle.
a
If you cannot install the projector squarely facing the screen, correct
any resulting keystone distortion using the projector controls. For the
best quality images, we recommend adjusting the installation position
of the projector to achieve the correct image size and shape.
• When you install the projector to a fixed location, turn on the Fixed
Installation setting in the projector's Installation menu.
• When you place the projector vertically, turn on the Vertical Installation
setting in the projector's Installation menu.
