Image Shape
63
You can project an even, rectangular image by placing the projector directly
in front of the center of the screen and keeping it level. If you place the
projector at an angle to the screen, or tilt it up or down, or off to the side, you
may need to correct the image shape.
After correction, your image is slightly smaller.
For the best quality images, we recommend adjusting the installation position
of the projector to achieve the correct image size and shape.
gg Related Links
• "Correcting the Image Shape with the Keystone Buttons" p.63
• "Correcting the Image Shape with Quick Corner" p.64
• "Correcting Image Shape with Arc Correction" p.66
• "Correcting Image Shape with Point Correction" p.69
• "Loading Image Shape Setting from Memory" p.71
• "Correcting Image Shape with Corner Markers" p.71
Correcting the Image Shape with the Keystone
Buttons
You can use the projector's keystone correction buttons to correct the shape
of an image that is unevenly rectangular.
You can use keystone buttons to correct images up to 3º right, left, up, or
down.
a
• If you change the Screen Type and Screen Position settings, the
adjustments are reset.
• You cannot combine with other correction methods.
a
Turn on the projector and display an image.
b
Press one of the keystone adjustment buttons on the control panel to
display the Keystone adjustment screen.
To Next Page
