Image Quality Settings - Image Menu
217
Setting Options Description
Detail
Enhancement
Creates a more emphatic texture and
material feel of the image.
Reset Resets all adjustment values on the
Image Enhancement setting to their
default settings.
Gamma -2 to 2
Custom
Adjusts the coloring by selecting one of
the gamma correction values, or referring
to a gamma graph.
RGBCMY Various levels
available
Adjusts the hue, saturation, and
brightness of each color R (red), G
(green), B (blue), C (cyan), M (magenta),
Y (yellow) individually.
Reset to Defaults — Resets all settings for the current color
mode.
Source — Displays settings saved for each input
source.
To change settings for an input source,
make sure the source is connected and
select that source.
Resolution Auto
Normal
Wide
Sets the input signal resolution if not
detected automatically using the Auto
option.
Setting is only displayed when the
current source is Computer.
Aspect See the list of
available aspect
ratios
Sets the aspect ratio (width-to-height
ratio) for the selected input source.
(Turn off the Scale setting or set the
Scale Mode setting to Full Display first
(EB‑755F/EB‑750F).)
Setting is only displayed when the
current source is Computer, Video or
HDMI.
Scale
(EB‑755F/EB‑750F)
Various scale
options
When using multiple projectors to
project one image, adjusts the scale of the
image displayed by each projector.
Setting Options Description
Analog Signal
Adjustment
Auto Setup Set to On to automatically optimize
computer image quality.
Setting is only displayed when the
current source is Computer.
Tracking Adjusts the signal to eliminate vertical
stripes in computer images.
Setting is only displayed when the
current source is Computer.
Sync. Adjusts the signal to eliminate fuzziness
or flickering in computer images.
Setting is only displayed when the
current source is Computer.
Position Adjusts the image location on the screen.
Setting is only displayed when the
current source is Computer or Video.
Reset to Defaults — Resets all settings for current input
source.
Reset Image
Settings
— Resets all adjustment values on the
Image menu to their default settings.
a
• The Brightness setting does not affect light source brightness. To
change the light source brightness, select the Light Source
Brightness Control setting in the projector's Operation menu.
• You can restore the default settings of the Tracking, Sync., and
Position settings by pressing the [Auto] button on the remote
control.
gg Related Links
• "Available Color Modes" p.82
• "Available Image Aspect Ratios" p.77
• "Scaling an Image" p.160
• "Adjusting the Image Color" p.84
