Projector Installation Settings - Installation Menu
221
Setting Options Description
Image Shift Various positions
available
Shifts the image position horizontally
and vertically.
This feature is not available if the Digital
Zoom option is set to the widest setting.
Connect ELPCB02
(EB‑735Fi/EB‑735F
/EB‑725Wi/EB‑725
W/EB‑720)
On
Off
Set to On to switch the input source
between HDMI2 and HDMI3 each time
you press the [HDMI2] button on the
optional interface box (ELPCB02).
Touch Unit
(EB‑735Fi/EB‑725
Wi)
— See the Pen/Touch menu table for details
on the Touch Unit settings.
Remote Receiver Front/Rear
Front
Rear
Off
Limits reception of remote control
signals by the selected receiver; Off turns
off all receivers.
Projector ID
(EB‑735Fi/EB‑735F
/EB‑725Wi/EB‑725
W/EB‑720)
Off
1 through 9
Assigns an ID for the projector when you
use multiple projectors.
Screen Type 4:3
16:6
16:9
16:10
Sets the aspect ratio of the screen to fit
the image into the projection area.
16:6 is available with
EB‑755F/EB‑750F/EB‑735Fi/EB‑735F
only.
Setting is only displayed when Content
Playback is set to Off.
(EB‑755F/EB‑750F)
Screen Position Various positions
available
Shifts the image position horizontally
and vertically.
This feature is not available if you set the
Screen Type setting to the same aspect
ratio as the projector resolution.
High Altitude
Mode
On
Off
Regulates the projector’s operating
temperature at altitudes above 1500 m.
Setting Options Description
Reset Installation
Settings
— Resets all adjustment values on the
Installation menu to their default
settings, except for the following:
• Digital Zoom
• Image Shift
gg Related Links
• "Projection Modes" p.55
• "Image Shape" p.63
• "Projector Setup and Installation Options" p.29
• "Projector Pen And Touch Setup Settings - Pen/Touch Menu" p.237
• "Focusing the Image" p.59
• "Resizing the Image with the Buttons" p.73
• "Setting the Screen Type" p.57
