Make sure you fix the lens unit removal button with the screw to
prevent the lens unit from being stolen.
Attention
• Store the projector with the lens unit installed.
If the projector is stored without the lens unit, dust and dirt may get inside
the projector and cause malfunctions or lower the quality of projection.
• When the projector is facing up (35 to 150 degrees) or down (-35 to
-150 degrees), tighten the lens torque ring. Note that it could malfunction if
it is over tightened.
a
To make sure that keystone correction is performed correctly, set the
Lens Type in the Configuration menu according to the lens you are
using.
s
Extended - Operation - Lens Type p.96
Removing
Attention
• Only remove the lens unit when necessary. If dust or dirt enter the projector,
projection quality deteriorates and it could cause a malfunction.
• Try not to touch the lens section with your hand or fingers. If fingerprints or
oils are left on the surface of the lens, projection quality deteriorates.
• If the lens shift has been done, set the lens shift to the center before replacing
the lens unit.
s "Adjusting the Position of the Projected Image (Lens Shift)" p.30
a
When the lens unit removal button is fixed with a screw, remove
the screw.
b
While pressing the lens unit removal button, turn the lens unit
counterclockwise until you hear it click.
Installing the Projector
25
