Epson EB-G6170 User Manual

Submenu Function
Edge Blending
Set to On to activate the edge blending function.
Set to Off when not projecting from multiple
projectors.
Top Edge/Bottom
Edge/Right Edge/Left
Edge
Blending: Set to On to activate the edge blending
function towards where you are setting, and the
brend range will be shaded.
Blend Range: Adjusts the range to be shaded.
Adjustment is possible at the level of one pixel. The
maximum range is 45% of the resolution.
Blend Curve
You can select from three ways of shading.
Guide Display
Set to On to display the guide on the edge blending
setting range.
Pattern Guide
Set to On to display a guide to match the position of
the edge blending setting range.
Guide Colors
You can select the combination of guide colors
from the three.
d
Turn on Edge Blending.
(1)
Select Edge Blending, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
e
Display the guide.
(1)
Select Guide Display, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
a
If the guide is not clear, you can change the color of the guide
on Guide Colors.
f
Display a pattern.
(1)
Select Pattern Guide, and then press the [
] button.
(2)
Select On, and then press the [
] button.
(3) Press the [Esc] button.
g
Set Top Edge/Bottom Edge/Right Edge/Left Edge.
(1)
Select Top Edge/Bottom Edge/Right Edge/Left Edge to set the edge
blending, and then press the [
] button.
(2)
Select Blending, and then press the [
] button.
(3)
Select On, and then press the [
] button.
(4) Press the [Esc] button.
Multi-Projection Function
67
