Projector Parts and Functions
23
Projector Parts - External Camera
You can attach the optional external camera to the front of the projector or
lens. See the external camera manual for the installation method.
Name Function
A
Camera lens Takes photos.
Attention
Do not use or store the external camera in
places where it will be exposed to strong light.
Otherwise, burning or malfunction may occur.
Name Function
B
Indicator light Indicates the external camera's status.
• Lit: standby
• Flashing (250 ms intervals): external camera is
malfunctioning
• Flashing (500 ms intervals): external camera is
operating
• Flashing (1000 ms intervals): updating the firmware
C
micro USB-B port Connects the supplied USB cable to the projector.
D
Screw holes (for
installation)
Secures the mount for installing the external camera.
gg Related Links
• "External Camera Usage" p.122
