Attaching and Removing a Lens

Pinch the lock lever and move it to the Release position.

When using one of the following lenses, attach the lens

connector cap to protect the port.

• ELPLS04

• ELPLU02

• ELPLR04

• ELPLW04

• ELPLM06/ELPLM07

• ELPLL07
