(2) Brightness Level (EB-Z8455WU/Z8450WU/Z8355W/Z8350W/Z10005/Z10000 only)
Adjust the Brightness Level so that the brightness of the lamp for each
projector matches.
Press the [Menu] button > Extended > Multi-Projection > Brightness
Level
Adjust so that all projectors are the same brightness as the darkest lamp.
You can adjust the brightness in five levels.
a
• Set Power Consumption to Normal 1.
Press the [Menu] button > Settings > Power Consumption
• Even if you adjust the Brightness Level, the brightness of each lamp
may not match exactly.
(3) Edge Blending
Fine tune overlapping areas to make seamless screen.
Perform this in Edge Blending from the Configuration menu.
Press the [Menu] button > Extended > Multi-Projection > Edge Blending
The following screen is displayed.
Operations
a
From the screen above, set Edge Blending and Guide Display to
On.
b
Set Edge according to the parts of the image that overlap.
Example: When setting the screen in (1)
(1)
The top and left edges of the projected image overlap, so select Top
Edge and Left Edge, and then set Blending to On.
Projecting Images
39
