Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
Appendix Parts List 124
552 RETAINING RING(B150300911)
556 "COVER, PAPER EJECT"
557 "FRAME,PAPER EJECT;EPAG"
560 "LEAF SPRING,PAPER EJECT,DOUBLE"
561 "SPUR GEAR,15"
562 "SPUR GEAR,11.5"
563 "LEAF SPRING,PAPER EJECT,SINGLE"
564 "ROLLER,PAPER EJECT,DRIVE"
568 "HOLDER,CABLE,HEAD"
569 "ROLLER ASSY,DRIVE"
570 PLATEN ASSY.
572 "BUSHING,8,RIGHT"
573 "COVER,PLATEN"
574 "BUSHING,8,LEFT"
575 RIBBON MASK
576 "PAPER GUIDE ASSY.,SUPPORT"
577 "GUIDE,PAPER LOAD"
578 "FRAME,REAR"
579 "FRAME,FRONT"
580 "FRAME,SUB,RIGHT"
581 "GROUNDING PLATE,MECHA"
582 "FRAME,BASE"
583 "BUSHING,PARALLEL,ADJUST"
584 "LEVER,GAP,ADJUST"
585 "CAP,LEVER;EDGB"
Table 7-11. Parts List - FX-890
REF# DESCRIPTION
587 "MOUNTING PLATE,MOTOR,CR"
588 "HOLDER,RIBBON MASK"
589 OIL PAD(F334005140)
590 "LEVER,RELEASE;EDGB"
591 "CAM,CLUTCH,TRACTOR"
592 "HOLDER,CABLE"
593 "COMBINATION GEAR,31,5,8"
594 "SPUR GEAR,27"
595 "SPUR GEAR,34.5"
596 "SPUR GEAR,34"
597 "SPUR GEAR,15"
598 INTERMITTENT GEAR
599 "LEVER,RELEASE,TRANSMISSION;W"
600 "EXTENSION SPRING,71"
601 "COMPRESSION SPRING,200"
602 "SPRING PIN,2X18,F/B"
603 C.B.S(P).(0) SCREW
607 PLAIN WASHER(B100166012)
608 C.B.SCREW(B010303411)
609 C.B.SCREW(B010303511)
610 C.B.S. SCREW(B300204311)
613 "SHAFT,MOUNT,CR"
614 TOOTHED LOCK WASHER A
615 HEXAGON NUT(B070200411)
617 LEAF SPRING(B101253990)
Table 7-11. Parts List - FX-890
REF# DESCRIPTION

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
