Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
PRODUCT DESCRIPTIONS Features 17
ELECTRICAL SPECIFICATION
Table 1-16. 120V Version
Table 1-17. 230V Version
Table 1-18. UPS Version
Note “*” : Upon a lapse of 5 minutes under the following conditions, the printer enters sleep
mode:
• Not in Pause, not in error status
• There is no data in input buffer.
Rated voltage AC 120 V
Input voltage range AC 103.5 to 132 V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 1.1 A (Max. 2.5 A)
Power consumption
Approx.53 W (ISO/IEC 10561 Letter pattern)
Approx. 3.5 W in sleep mode *
0 W in power off mode
Energy Star compliant
Insulation resistance 10 MΩ min. (between AC line and chassis, DC 500 V)
Dielectric strength
AC 1000 V rms. 1 min. or AC 1200 V rms. 1 sec.
(between AC line and chassis)
Rated voltage range AC 220 to 240 V
Input voltage range AC 198 to 264 V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 0.6 A (Max. 1.3A)
Power consumption
Approx. 53 W (ISO/IEC 10561 Letter pattern)
Approx. 3.5 W in sleep mode *
0 W in power off mode
Energy Star compliant
Insulation resistance 10 MΩ min. (between AC line and chassis, DC 500 V)
Dielectric strength AC 1500 V rms. 1 min. (between AC line and chassis)
Rated voltage range AC 100 to AC240V
Input voltage range AC 90 to 264V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 1.1 A (Max. 3.0 A)
Power consumption
Approx.56 W (ISO/IEC 10561 Letter pattern)
Approx. 4.0 W in sleep mode *
0 W in power off mode
Energy Star compliant
Insulation resistance 10 MΩ min. (between AC line and chassis, DC 500 V)
Dielectric strength AC 1500 V rms. 1 min. ( between AC line and chassis)

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
