Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
PRODUCT DESCRIPTIONS Features 18
ACOUSTIC NOISE
Level: 55 dB(A) (ISO 7779 pattern)
ENVIRONMENTAL CONDITIONS
Temperature : 5 to 35°C (operating,
*1
)
15 to 25°C (operating,
*1,*2
)
-30 to 60°C (non-operating)
Humidity : 10 to 80 % RH (operating,
*1
)
30 to 60 % RH (operating,
*1,*2
)
0 to 85 % RH (non-operating)
Resistance to shock : 1 G, within 1ms (operating)
2 G, within 2ms (non-operating)
Resistance to vibration : 0.25 G, 10 to 55 Hz (operating)
0.50 G, 10 to 55 Hz (non-operating)
*1: without condensation
*2: during printing on reclaimed paper, multi part paper, envelope, label or roll paper
RELIABILITY
Total print volume (MVBF) 52 million lines (except print head)
MTBF 20000 POH (25% Duty)
Print head life 400 million strokes/wire
(Approx. 400 million characters (Draft 10 cpi, 14 dots/
character))
RIBBON CARTRIDGE
<FX-890>
Type Fabric
Color Black
Ribbon dimensions 13 mm (W) x 17 M (L) Endless
Ribbon life Approximately 7.5 million characters
(Draft 10 cpi, 14 dots / character)
Cartridge dimensions 287 mm (W) x 30 mm (H) x 77 mm (D)
<FX-2190>
Type Fabric
Color Black
Ribbon dimensions 13 mm (W) x 19 M (L) Endless
Ribbon life Approximately 12 million characters
(Draft 10 cpi, 14 dots / character)
Cartridge dimensions 468.5 mm (W) x 34 mm (H) x 78 mm (D)
SAFETY APPROVALS

120 V version
 Safety standards UL 1950, CSA C22.2 No. 950
 EMI FCC part 15 subpart B class B, CSA C108.8 class B
 230 V version
 Safety standards EN60950
 EMI EN55022 ( CISRP pub.22 ) class B
AS/NZS.3548 class B
 UPS Version
 Safety standards UL 1950, CSA C22.2 No. 950
EN60950
 EMI FCC part 15 subpart B class B, CSA C108.8 class B
EN55022 (CISPR pub. 22) class B
AS/NZS 3548 class B

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
