Page #63 background image
EPSON FX-890/2190 Revision B
Troubleshooting Troubleshooting Based on Symptoms 63
3.2.12 Fatal Error
Table 3-14. Troubleshooting for Fatal Error
Action and Question Yes No
Parts below can be the source of this error (Chapter 4 Disassembly and Assembly)
C524MAIN Board (p.74)
C524PSB/PSE/PSH Board (p.76)
Printhead (p.77)
CR Motor (p.81)
PF Motor (p.83)
HP (Home Position) Detector (p.78)
Abnormal +42V Drive Voltage
(PD Error : value = 37H)
The printer detects abnormal voltage level with +42V line.
Check to see if the components to which +42V is supplied; is
defective (short-circuit).
Printhead
•CR Motor
PF Motor
Replace the
defective
component.
Replace the
power supply
circuit board
(C524PSB/
PSE/PSH).
Abnormal CR operation
(CR Error : value = 30H)
CR Home position seek operation is failed, or CR Home
position is detected during printing.
Check to see if one of the following component is defective.
•CR Motor
Timing belt tension
•CR HP Sensor
Replace the
defective
component.
Replace
C524MAIN
Board.
CG Access Error
(CG Error : value = 33H)
Failed to access CG, or error in EEPROM data verification.
Check to see if an error solved by replacing the C524MAIN
board.
Replace
C524MAIN
Board.
Go to 3.2.11
Electrical
Noise (p.62)
Abnormal Printhead Temperature
(Head Open Error : value = 3AH)
The printer actually checks the connection between the
printhead and C524MAIN Board, and an error is recognized
as an abnormal printhead temperature if the connection is
wrong.
Check to see if the connection between the printhead and
C524MAIN Board is correct.
FFC is not properly connected (or disconnected).
FFC is damaged.
Re-connect
FFC or replace
the defective
component.
Replace the
printhead.
Abnormal Printhead TrVce Voltage
(VDD Error : value = 36H)
The level of drive voltage supplied to the printhead is
abnormal.
Replace the
power supply
circuit board
(C524PSB/
PSE/PSH).
Replace the
printhead.
Abnormal voltage with the simple ecodrive circuit
(ECO Error : value = 3CH)
The printer check the operation of simple ecodrive circuit
when it is turned on, and recognizes this error condition if the
voltage level is abnormal.
Replace
C524MAIN
Board.
Replace the
power supply
circuit board
(C524PSB/
PSE/PSH).
Table 3-14. Troubleshooting for Fatal Error (continued)
Action and Question Yes No
