4.1.3.1 Abbreviations for Small Parts
The table below lists the abbreviations used in this manual for small parts, such as
screws and washers.
Table 4-3. List of Screws Used
No. Name and specification Shape
1 CBS (M3x6)
2 CBS (M3x12)
3
PLASTIC HEAD
P TITE,4X13
4 CBP (M4x12)
5 CBS (M3x8)
6 CBP (M3x8)
7 CBP (M3x12)
8 CBS (M3x4)
9 CBS (M3x8) C(P2)
10 CB (0) (M4x8)
11
PRINTER
MECHANISM
MOUNTING SCREW
12 CP (M3x4)
13
SHAFT,MOUNT,CR
(M8x10)
14 CB (M3x6)
15 CBS (M3x10)
16
Hexagon nut
normal(M4)
Table 4-3. List of Screws Used
No. Name and specification Shape
