Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
PRODUCT DESCRIPTIONS Dimensions and Weight 42
1.4.1.3 Default setting items
Note : Settings with bold weight mean the default setting.
1.4.1.4 Printer defaults
FX-880T+ mode has different defaults from current FX-890 mode as follows.
N
Note “*” : IBM PPDS is same as IBM 238x plus.
1.4.1.5 Action of the printer
 Interface
FX-880T+ mode does not have Device ID.
Only Parallel I/F is possible use. (Can not use USB I/F and Optional Type-B I/F)
 Tear Off
When the Tear Off button is pushed, the printer sends the present printing position
in the Tear Off position.
If the Auto Tear Off setting is On, the printer always do the Tear Off action when
it is not printing.
 TOF position (MicroAdjust)
The setting range of Micro Adjust is 4.2mm to 22mm to 558.8mm(22inch).
NOTE: * Don’t set up TOF more largely than Page length.
Table 1-40. Setting Values Available for Default Setting Mode
Item Setting / Value
Software
ESC/P, IBM PPDS, OKI ML320T
*IBM PPDS is the same as IBM 238x plus.
Auto tear Off Wait Time 0.5 second, 1 second, 2 seconds, others
Bottom margin
4.2 mm, 20 mm, 22 mm, 24 mm
, others
*When “24 mm” is selected, the printer acts with approx.23.5 mm
Line Spacing 6LPI, 8LPI
Paper Out Override OFF (No), ON (Yes)
Table 1-41.
Items Current FX-890 FX-880T+ (=ML320T)
Software ESC/P IBM PPDS (*)
Top margin 4.2 mm 22.5 mm
Bottom margin 4.2 mm 24 mm
Auto tear Off Wait Time 3.0 sec. 0.5 sec.

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
