Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
PRODUCT DESCRIPTIONS Interface 25
1.2.2 Parallel interface (Reverse channel)
 Specifications
 Transmission mode : IEEE-1284 nibble mode
 Adaptable connector: 57-30360 (Amphenol) or equivalent
 Synchronization : Refer to the IEEE-1284 specification
 Handshaking : Refer to the IEEE-1284 specification
 Signal level: TTL compatible (IEEE-1284 level 1 device)
 Data transmission timing : Refer to the IEEE-1284 specification
 Extensibility request : The printer responds to the extensibility request in
the affirmative, when the request is 00H or 04H,
which mean;
00H : Request nibble mode of reverse channel transfer
04H : Request device ID in nibble mode of reverse channel transfer
 Device ID: The printer sends the following device ID string when it is requested
 FX-890
When IEEE1284.4 is enabled,
When IEEE1284.4 is disabled,
 FX-2190
When IEEE1284.4 is enabled,
When IEEE1284.4 is disabled,
[00H][4CH]
MFG:EPSON;
CMD:ESCP9,PRPII9,BDC,D4;
MDL:FX-890;
CLS:PRINTER;
DES:EPSON[SP]FX-890;
[00H][49H]
MFG:EPSON;
CMD:ESCP9,PRPII9,BDC;
MDL:FX-890;
CLS:PRINTER;
DES:EPSON[SP]FX-890;
[00H][4EH]
MFG:EPSON;
CMD:ESCP9,PRPII9,BDC,D4;
MDL:FX-2190;
CLS:PRINTER;
DES:EPSON[SP]FX-2190;
[00H][4BH]
MFG:EPSON;
CMD:ESCP9,PRPII9,BDC;
MDL:FX-2190;
CLS:PRINTER;
DES:EPSON[SP]FX-2190;

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
